ABOUT US

AquaTrip is a permanently installed Leak Detection System with an integrated automatic Shutoff Valve.

It functions as a Water Trip Switch, constantly monitoring all the plumbing pipes, fittings and water using appliances on the property.



If it detects a leak, a tap left running or some other plumbing failure, it will shut off the water automatically, to minimize water damage, prevent excess water bills and save water.



You can easily turn the water back on when required.

Aquatrip Canada Pty. Ltd.       All rights reserved - © 2017

AVAILABLE IN CANADA FROM:

CUPRO DISTRIBUTION INC.

PO BOX 31145 RPO THUNDERBIRD,

LANGLEY BC

V1M 0A9



EMAIL:  info@dcpro.ca

Where can you buy an Aquatrip?

AquaTrip

around the world

How can an

Aquatrip help

TERMS, CONDITIONS OF SALE & WARRANTY:

Click HERE

LEAK

  DETECTION

SYSTEMS

For Whole House Monitoring

AT201

MANUAL CONTROL SYSTEMS

AT301

REMOTE CONTROL SYSTEMS

AT401

HARD WIRED SYSTEMS

AT201   -  Standard Manual Control Leak Detection System

The AT201 is a programmable Leak Detection System with automatic  shutoff valve. It is easily fitted inline on your main incoming water pipe, and acts as a Water Safety Trip Switch, monitoring all your plumbing. It is designed to detect the difference between your normal water use and a leak, and will shut off the water if a leak is detected or a tap, hose or appliance is left running.



Simple to use with only one button to control all functions. It is powered by a long life battery (supplied) so needs no wiring or electrical connection, and can be mounted above or below ground either inside or outside*.   It can be used in Houses, Apartments or Commercial washroom applications.



The AT201 also has a selectable Sleep Mode for use with Irrigation systems or if used to monitor public washrooms, it can sleep during very busy periods of non stop water use by patrons.



• Patented Leak Sensor with integrated shutoff valve, shuts off water once leak is detected

• Leak Detection Sensing System is programmable to operate in almost any application

• Fast Test Facility allows rapid check of system functions

• Powered by long life 9v battery (supplied)

• Two digit LED status display

• Leak counter display (up to 99) with counter reset facility

• Simple stand alone installation - no wires to connect

• Input port for connection to optional external reset switches or movement sensors

• Sleep Mode for use with Irrigation or for peak hours in busy commercial facilities

• Easy one button operation for all functions and programming

• Low battery warning indicator - water turns off

• Battery power level indicator on LED status display

• Temporary System Override facility

• Emergency manual Total System Override facility

• Service Plug supplied allows for Control Unit maintenance

• Early Warning Indication warns user before water is shut off

• Submersible installation allowed (To 2m Depth - Equiv to IP68+)



Available with a choice of PVC or Stainless Steel Shutoff Valves
to suit your incoming pipe size and material



* subject to environmental conditions - see Installation Manual

AT201 with 20mm

Stainless Steel Valve

option shown



AT301 -  Deluxe Remote Control Leak Detection System

The AT301 is an advanced wirelessly controlled programmable Leak Detection System with automatic shutoff valve. It is easily fitted inline on your main incoming water pipe, and acts as a Water Safety Trip Switch, monitoring all your plumbing. It is designed to detect the difference between your normal water use and a leak, and will shut off the water if a leak is detected or a tap, hose or appliance is left running.

The system is controlled by the portable wireless Control Panel which is used to program and operate all the functions of the system. The system is powered by long life batteries so needs no wiring or electrical connection.

• Patented Leak Sensor with integrated Shutoff Valve. Shuts off water once leak is detected
• Portable wireless Control Panel to easily program and control the system
• Fast Test Facility allows rapid check of system functions
• System Check Procedure assists in quick identification of leaks once detected
• Early Warning Indicator alerts user to impending water shut off - e.g. prevents user being caught in the shower with no water
• Home/Away mode for increased leak detection protection - Automatic or Manual settings available
• Battery Power Level indicators with low battery warning alarm
• Night watch mode for increased overnight leak detection sensitivity
• Sleep Mode - Programmable exclusion period disables flow monitor if required - e.g. for when using garden irrigation
• Short term system override from Control Panel for occasional longer than normal water usage
• Emergency manual override facility if system needs to be turned off for building work/maintenance
• Water can be shut off from the Control Panel - no need to access the incoming main tap for plumbing maintenance
• Replaceable mesh filter protects sensing hardware from debris in water supply
• Accessory Port may allow connection of movement sensors, hard wired reset switches or water meter signal input.
• Available with a choice of PVC or Stainless Steel Shutoff Valves to suit your incoming pipe size or material.



AT401 - Deluxe Hard Wired Leak Detection System

The AT401 is one of the most advanced Water Management, Leak Detection and Control Systems available on the market today. Designed to look as smart as it is functional, it uses a sleek wall mount Control Panel from which the user can control all the functions and programming of the system. The ultimate and most advanced water safety Trip Switch for plumbing protection.

The Control Panel is connected by a low voltage signal cable to the Shutoff Valve, which is mounted inline on your main incoming water pipe. This allows the AT401 to monitor all the plumbing in the house.

The AT401 is powered by a plug in 12v transformer and has a built in backup battery in case of mains power failure. It can be finely programmed for optimum leak protection.
• Wall mount deluxe Control Panel with large backlit LCD display allows easy control of the system
• Patented Leak sensor with integrated Shutoff Valve, shuts off water once leak is detected

• Cable connection between the Control Panel and the Shutoff Valve for instant response (cable not supplied)
• Back up battery in case of mains power failure
• Water Flow indicator on the Control Panel for instant visual confirmation of water flow or a potential leak
• Fast Test Facility allows rapid check of system functions
• Early Warning Indicator alerts user to impending water shut off - e.g. prevents user being caught in the shower with no water
• Home/Away mode for increased leak detection protection - Automatic or Manual settings available
• Nightwatch mode for increased overnight leak detection sensitivity
• Sleep Mode - Programmable Exclusion Period disables Flow Sensor when required - e,g, for when using garden irrigation
• Short term system override from Control Panel for occasional longer than normal water usage
• Emergency manual override facility if system needs to be turned off for building work/maintenance
• Water can be shut off from the Control Panel - no need to access the incoming main tap for plumbing maintenance
• Replaceable mesh filter protects units from debris in water supply
• Accessory Port may allow connection of movement sensors, extra reset switches or water meter input signal.
